Bridge Saws

MSA

Miter saw for 45 degree cutting MSA
Miter saw for the professional tilted cutting at 45 degrees

Professional stone saw for tilted cuts designed to work slabs "face down", it will perform perfect 45 degree cuts even on uncalibrated slabs. No width limitation of the slab to process; even the most narrow strips can be machined thanks to the special pneumatic pistons to secure the stone. The maximum cutting precision is guaranteed by the head travel on linear guides fitted with recirculating ball slides and by the position of the blade cutting from bottom upwards.

ADVANTAGES

MSA professional miter saw for tilted cuts:

  • Steel frame with hot-dip galvanizing treatment for maximum resistance to wear and rust;
  • Worktable made of anti-scratch plastic slats;
  • Maximum cutting precision is guaranteed by the head travelling on linear guides fitted with recirculating ball slides automatically lubricated;
  • 10 pneumatic pistons and 3 slab stops to secure even the smallest workpieces in place during machining;
  • Pneumatic pop-up slab stops to cut thin ceramic and sintered material slabs;
  • Digital displays to visualize disc rpm, feed speed and main motor ammeter;
  • Removable plastic splash guards, along the entire worktable;
  • Precision handwheel to adjust the blade position when the cut does not start on the sharp corner.

TECHNICAL DETAILS

X axis travel3300 / 3700 mm
Worktable dimensions3300/3700 x 1000 mm
Diamond blade diameter350-400-450 mm
Blade bore sizeAccord
Min/Max stone thickness0-80 mm (with pneumatic slab stops)
Main motor power5,5kW = 7,5HP trifase
Main motor rotation speed (opt.) 800 – 3400 rpm
Standard voltage/ frequency3ph. 400V-50/60Hz 230V-60Hz

STRUCTURE

Steel frame hot-dip galvanized.

SLAB SECURING

10 pneumatic pistons and 3 removable weighted plates to secure small pieces in place during machining.

WORK TABLE

Work table made of anti-scratch plastic strips.

HEAD FEED

Motorized head travel with variable speed on linear guides fitted with automatically lubricated recirculating ball slides

ACCESSORIES
